HJF-1400injection molding machine
Electric Unit Advantages
Standard equipped three‐color tower light with alarm, machine working situation is clear.
Water‐proof rubber seal used in electric cabinet, ensure high safety.
Electronically Controlled Unit
1. CPU controller and display are independent and reliable.
2. A larger color LCD screen enhances clear display and support multi-language compatibility.
3. The control system also support remote monitor.In the event of a control problems,the machine can be connected to internet through a special interface.Inject service can realize remote fault diagnosis and maintenance.
4. A screen saver function extends the LCD life.
5. Ultra bright LED is provided for input and output point inspection.Proving convenient indication of the machine’s operation and machine service.
6. A data hardware lock is provided to prevent unauthorized people from effecting the machines performance.
7. Closed loop PID barrel temperature control.
8. Dust and waterproof control cabinets provide a neat and tidy enclosure all electric control components.
| SPECIFICATION |
HJF-1400 |
| |
A |
B |
C |
D
|
| Screw diameter |
mm |
110 |
120 |
130 |
140 |
| Screw L/D Ratio |
L/D |
26.2 |
24 |
21 |
20.2 |
| Shot size(theoretical) |
cm³ |
5414 |
6443 |
7561 |
8770 |
| Injection weight(PS) |
g |
4872 |
5798 |
6805 |
7893 |
| Injection pressure |
Mpa |
205 |
170 |
143 |
123 |
| Injection rate |
g/s |
793 |
867 |
944 |
1024 |
| Screw Speed |
rpm |
90 |
| Clamp tonnage |
KN |
14000 |
| Opening stroke |
mm |
1300 |
| Space between the tie bars |
mm |
1350*1250 |
| Max.Mold Height |
mm |
1250 |
| Min.Mold Height |
mm |
550 |
| Ejector stroke |
mm |
325 |
| Ejector tonnage |
KN |
215 |
| Max.pump pressure |
Mpa |
16 |
| Pump motor power |
KW |
55+55 |
| Heater power |
KW |
85.25 |
| Machine dimension(L*W*H) |
M |
13.1*3.0*3.2 |
| Machine weight |
T |
60 |
| Oil tank capacity |
L |
2400 |
Haijiang Machinery Main Configuration
| Controller |
Arcuchi/Porchesion(50-290T)(China) |
| Techmation(360-3000T)(Taiwan) |
| Vane pump |
Albert(USA) |
| Proportional valve |
HJK series Northman(TAIWAN) |
| HJK series Northman(TAIWAN) or TOKIMEC(Japan) |
| Directional valve |
HNC(TAIWAN) or YUKEN(Japan) |
| Electric motor |
Dongguan(Guangdong) |
| contactor |
Mager(50-290T)/Schneider(China)(360-3000T) |
| High pressure hose |
Fute(Ningbo) |
| Five-star hydrauhu |
Dandun(China)STAFFA(UK) |
| Air breaker |
LS(Korea) |
| Thermal overland relay |
Schneider(China) |
| Limit switch |
Omoron(Japan) |
| Lubrication pump |
Automatic |
| Servo motor |
SUMITOMO(Japan) |
| Servo pump |
DELTA(Taiwan) |
| Servo sensor |
ASHCROFT(Germany) |
SPARE PARTS(FOR FREE)
| 1.mold clamping with bolts:8pcs |
2.Nozzle:1pc |
| 3.Toolbox:1set |
4.heating ring:2pcs |
| 5.lubrication oil:1 bucket |
6.limit switch:2pcs |
| 7.hexagon wrench:1set |
8.thermocouple:2pcs |
| 9.seal ring:2pcs |
10.machine foot pad:6pcs |
| 11.vise:1pc |
12.power socket for auxiliary machine:2pcs |
| 13.wrench:1pc |
14.screwdriver:2pcs |
